Product Features
l Up to 1.25Gb/s data links
l Up to 10/40/80/120/160km on 9/125µm SMF
l Hot-pluggable SFP footprint
l BIDI LC/UPC type pluggable optical interface
l RoHS compliant and lead-free
l Support Digital Diagnostic Monitoring interface
l Single +3.3V power supply
l Metal enclosure, for lower EMI
l Meet ESD requirements, resist 8KV direct contact voltage
l Case operating temperature : -40°C to +85°C
| Product Number | Data Rate (Gb/s) | Wavelength (nm) | Rearch (Km) | LD | Tx Power (dBm) | PD | Rx Sens (dBm) | Temperature (℃) | Download |
| BIDI LX | 1.25 | 1310/1490 | 10 | FP | -9～-3 | PIN | < -20 | -40~85 | |
| BIDI EX | 1.25 | 1310/1550 | 40 | DFB | -5~0 | PIN | <-24 | -40~85 | |
| BIDI ZX | 1.25 | 1490/1550 | 80 | DFB | 0～5 | PIN | <-26 | -40~85 | |
| BIDI ZX+ | 1.25 | 1490/1550 | 100 | DFB | 0～5 | APD | < -30 | -40~85 | |
| BIDI ZX++ | 1.25 | 1490/1550 | 120 | DFB | 0～5 | APD | < -31 | -40~85 |
