Product Features
l Up to 11.3Gb/s data links
l CWDM EML transmitter and PIN receiver
l Up to 40/80/100km on 9/125µm SMF
l Hot-pluggable SFP+ footprint
l Duplex LC/UPC type pluggable optical interface
l RoHS-10 compliant and lead-free
l Support Digital Diagnostic interface
l Single +3.3V power supply
l Compliant with SFF+MSA and SFF-8472
l Metal enclosure, for lower EMI
l Meet ESD requirements, resist 8KV direct contact voltage
l Case operating temperature : -40°C to +85°C
| Product Number | Data Rate (Gb/s) | Wavelength (nm) | Rearch (Km) | LD | Tx Power (dBm) | PD | Rx Sens (dBm) | Temperature (℃) | Download |
| CWDM LR | 10 | 1270-1610 | 10 | DFB | -6~-0.5 | PIN | -14.4 | -40~85 | |
| CWDM ER | 10 | 1470-1610 | 40 | EML | -1~3 | PIN | <-15.8 | -40~85 | |
| CWDM ZR | 10 | 1470-1610 | 80 | EML | 0～5 | APD | < -23 | -40~85 | |
| CWDM ZR+ | 10 | 1470-1610 | 100 | EML | 1～6 | APD | < -25 | -40~85 |
