Product Features
l Up to 11.3Gb/s data links
l Up to 10/40/80/120km on SMF
l Hot-pluggable SFP+ footprint
l Duplex LC/UPC type pluggable optical interface
l RoHS-10 compliant and lead-free
l Support Digital Diagnostic interface
l Compliant with SFF+MSA and SFF-8472
l Single +3.3V power supply
l Metal enclosure, for lower EMI
l Meet ESD requirements, resist 8KV direct contact voltage
l Case operating temperature : 0°C to +70°C/ -40°C to +85°C
| Product Number | Data Rate (Gb/s) | Wavelength (nm) | Reach (km) | LD | Tx Power (dBm) | PD | Rx Sens (dBm) | Temperature (℃) | Download |
| HXSX-AL311C/I | 10 | 1310 | 10 | DFB | -6.5～0.5 | PIN | < -14.4 | 0~70/-40~85 | |
| HXSX-AL541C/I | 10 | 1550 | 40 | EML | -1.0～3.0 | PIN | < -15.8 | 0~70/-40~85 | |
| HXSX-AL581C/I | 10 | 1550 | 80 | EML | 0～5.0 | APD | < -23.0 | 0~70/-40~85 | |
| HXSX-AL5W1C/I | 10 | 1550 | 100 | EML | 1.0～6.0 | APD | < -25 | 0~70/-40~85 | |
| HXSX-AL5X1C/I | 10 | 1550 | 120 | EML | 1～6 | APD | < -26 | 0~70/-40~85 |
