Product Features
l Up to 1250Mb/s data links
l CWDM DFB laser transmitter and PIN photo-detector
l Up to 40/80/120/160km on 9/125µm SMF
l Hot-pluggable SFP footprint
l Duplex LC/UPC type pluggable optical interface
l RoHS compliant and lead-free
l Single +3.3V power supply
l Support Digital Diagnostic interface
l Metal enclosure, for lower EMI
l Meet ESD requirements, resist 8KV direct contact voltage
l Case operating temperature : 0°C to +70°C/ -40°C to +85°C
| Product Number | Data Rate (Gb/s) | Wavelength (nm) | Reach (km) | LD | Tx Power (dBm) | PD | Rx Sens (dBm) | Temperature (℃) | Download |
| HXSC-1Lx21C/I | 1.25 | 1270-1610 | 20 | DFB | -9~-3 | PIN | <-20 | 0~70/-40~85 | |
| HXSC-1Lx41C/I | 1.25 | 1270-1610 | 40 | DFB | -5～0 | PIN | <-24 | 0~70/-40~85 | |
| HXSC-1Lx81C/I | 1.25 | 1270-1610 | 80 | DFB | 0～5 | PIN | <-26 | 0~70/-40~85 | |
| HXSC-1LxX1C/I | 1.25 | 1470-1610 | 100 | DFB | 0~5 | APD | <-30 | 0~70/-40~85 | |
| HXSC-1LxX1C/I | 1.25 | 1470-1610 | 120 | DFB | 0～5 | APD | < -31 | 0~70/-40~85 | |
| HXSC-1LxY1C/I | 1.25 | 1470-1610 | 160 | DFB | 1～6 | APD | < -33 | 0~70/-40~85 |
