l Compliant to Ethernet 100GBASE
l Support line rates from 103.125 Gb/s to 112 Gb/s OTU4
l Duplex LC optical receptacle
l QSFP28 MSA compliant
l Support Digital Monitoring interface
l Hot pluggable 38 pin electrical interface
l RoHS-10 compliant and lead-free
l Single +3.3V power supply
l Maximum power consumption 5.5W
l All-metal housing for superior EMI performance
l Case operating temperature: 0°C to +70°C/ -40°C to +85°C
| Product Number | Data Rate (Gb/s) | Wavelength (nm) | Reach (km) | LD | Tx Power (dBm) | PD | Rx Sens (dBm) | Temperature (℃) | Download |
| HX4X-CL311C/I | 100 | 1310 | 10 | DML | -4.3~4.5 | PIN | < -10.6 | 0~70/-40~85 | |
| HX4X-CL341C/I | 100 | 1310 | 40 | EML | -2.9～4.5 | APD | < -16.65 | 0~70/-40~85 | |
| HX4X-CL381C/I | 100 | 1310 | 80 | EML | 2.0～4.5 | SOA+PIN | < -23.0 | 0~70/-40~85 | |
| HX4X-CL3W1C/I | 100 | 1310 | 100 | EML | 2.0～4.5 | SOA+PIN | < -25.0 | 0~70/-40~85 |
